SPECIFICATIONS
|
ENGINE
|
Certification
|
EPA approved / CARB in process
|
Engine type
|
4-stroke,Single-Cylinder, Air/Oil-cooled
|
Displacement
|
168.9
|
Horse Power
|
10.3 H.P.
|
Valve Configuration
|
OHV
|
Compression ratio
|
9.2:1
|
FUEL SYSTEM
|
Fuel Delivery System
|
Fuel Pump Carburetor
|
Choke System
|
Manual Choke
|
Fuel capacity
|
3.1 Gallon
|
DRIVETRAIN
|
Driveline Type
|
2 x 4
|
Final Drive
|
Chain-drive
|
Transmission
|
Constantly Variable Speed Transmission
|
Gear Selection
|
Forward & Reverse Single Speed
|
ELECTRICAL SYSTEM
|
Forward Lights
|
Halogen headlights-High & Low Beam
|
Rear Lights
|
Brake Lights & Left/Right Signal lights
|
Starting system
|
Electric start
|
Ignition system
|
C.D.I.
|
SUSPENSION / BRAKES
|
Suspension Front
|
A-Arm Independent Shock 4 Travel
|
Suspension Rear
|
Dual Shock Single Axle 3 Travel
|
Brakes Front
|
Front Dual Hydraulic Disk
|
Brakes Rear
|
Rear Single Axle Hydraulic Disk
|
TIRES
|
Front Tread
|
1000mm(49.6in)d/1200mm(in)u
|
Rear Tread
|
970mm ( 48.4 in.)
|
Front & Rear tire size
|
19*7-8 / 20*10-9
|
| MISC. |
Top speed
|
30 M.P.H.
|
Dry weight
|
700 lbs.
|
Wheelbase
|
74.8in
|
Vehicle dimension(L*W*H)
|
87*45*56 |
Ground clearance
|
|
